FULL SPECS & FEATURES

WHAT'S INCLUDED IN THIS PLAN SET

Purchasing a CAD set gives you an unlimited build license.

• Cover Sheet – May include index, front view of home, definitions, etc.
• Foundation Plan – Typically includes dimensioned foundation plan with footing details.
• Dimensioned Floor Plan – Electrical may be shown.
• Exterior Views – Four exterior views of the residence with other miscellaneous details.
• Roof Plan – Birds eye view showing all ridges, valleys and other necessary information.
• Electrical Plan – Displays all lighting fixtures, outlets and other necessary electrical items. These items may be shown on the Dimensioned Floor Plan. Switches and arcs are not shown and should be located by owner/contractor at site.
• Wall Section(s) – Detail of wall materials and assembly.
• Building Section(s) – Section through home displaying necessary information about framing and other miscellaneous data.
• Cabinet Elevations – Displays interior kitchen cabinet views.
